50L Automatic Filling Packing Machine 20bph Bottle Screw Capping Machine

Name: 50L Automatic Filling Packing Machine 20bph Bottle Screw Capping Machine
Brand: Gracias
Price: 1 USD

50L Automatic Filling Packing Machine 20bph Bottle Screw Capping Machine Manufactures

Brand Name : Gracias

Place of Origin : China

MOQ : one set

Price : As discussion

Payment Terms : T/T, L/C

Supply Ability : 30sets per month

Delivery Time : 20-40work days

Packaging Details : fit for ocean shipping

Condition : New

Warranty : 1 Year

Voltage : 380V 50Hz 3phases

Pressure : 0.6-0.8Mpa

Color : Silver

Control system : PLC

Contact Now

50L Automatic Filling Packing Machine 20bph Bottle Screw Capping Machine

Machine characteristics
① The whole machine is made of corrosion-resistant stainless steel, which is easy to clean and disinfect, and meets the national regulations and requirements on food machinery and hygiene.
② This machine adopts German brand infrared sensor, and its position control is accurate.
③ This machine adopts imported PLC and 7-inch touch screen man-machine interface, production parameterized control, simple operation.
④ Equipped with height and width adjustment handwheels, it is convenient to adjust the height and left and right width of the labeling head to adapt to different products.
⑤ Adopt imported high-precision servo motor to drive labeling, labeling is accurate and stable.

Capping machine

Lid feeding form	Raise the belt style cover
Suitable specifications	According to the model provided by the customer
Capping form	Gripper cover to take the pneumatic screw cap(different specifications need to change the head and other accessories)
Speed	20bottle/min
Total power	500W
Air pressure	0.6-0.8Mpa
Voltage	220V Simplex

4 Piston filling machine

Filling heads	4 heads
Filling capacity	50-500ml
Filling form	Servo piston type
Speed	25-30bottle/min(50-150ml)
Accuracy	+-1%
Air pressure	0.6-0.8Mpa
Transport the motor	370W Variable frequency speed control motor
Power	2KW/380V 3 phase 5 line
Trough capacity	50L
Protective device	Liquid storage tank will alarm if lack of liquid

50L Automatic Filling Packing Machine 20bph Bottle Screw Capping Machine
