8m/Min 6T Rolling Shutter Manufacturing Machine Hydraulic Cutting

Brand Name : Gracias

Model Number : Rolling shutter door

Certification : CE,ISO

Place of Origin : China

MOQ : one set

Price : As discussion

Payment Terms : T/T, Western Union, L/C

Supply Ability : 50sets per month

Delivery Time : 20-40work days

Packaging Details : fit for ocean shipping

Voltage : 380V 50Hz 3phases

Condition : New

Use : Roller shutter door roll forming machine

Tile type : Steel,Colored Glaze Steel

Warranty : 12 Months

Control system : Taiwan Delta,PLC

Contact Now

8m/min 6T Rolling Shutter Manufacturing Machine Hydraulic Cutting

Product Description

1) Easy in installation and maintenance.
2) Hardened structural steel and components provide long life and safe operational stability.
3) Adopting advanced world famous brand components in controlling parts, electric parts and operation parts.
4) Running in an automation, high durability and stability.
5) Compact design, meet custom demands.

Features:

  • Lightweight, high impact strength and simple to use.
  • Deep corrugations provide bold aesthetic shadow effects.
  • The strength of design allows longer spanning or greater allowable loads.
  • Various corrugation profiles, including standard, mini, tile effect, box profile, etc.
  • Offer Custom-manufactured service to satisfy your special needs.
  • Offer roof materials in galvanised steel, prepainted galvanised steel, also available in galvalume steel and prepainted galvalume steel.
  • Offer roof accessories to help you install roof or wall panel, such as roof fasteners, roof panel machine and roof cutting tool.

Main forming machine

Raw material
Processing material Color steel coil, Galvanized coil, Aluminized zinc coil or as your customized
Processing thickness (mm) 0.3-1.0mm or as your customized
Material of rollers High grade 45# steel, Processed by CNC lathe, Hardening and tempering, polishing, hard chrome plated 0.05-0.07mm
Material of shafts 45# steel
Diameter of shafts 70mm or as your customized
Forming speed 8-12 m/min or as your customized
Under frame 350 H-beam
Sidewall 16mm
Connect bar 25mm, zinc plated
Forming steps 22 or as your customized
Control system Delta PLC and Inverter
Suitable power 380V, 50 Hz, 3 phase or according to your need
Drive mode Chain and sprocket, chain size 1 inch
Main motor 3-5.5kw
Hydraulic pump station 3-5.5kw
Cutting model Hydraulic profile cutting
Dimension of the machine 7.5m-11m×1.5mm×1.2m
Weight of the machine 3.5 ton -6 ton

8m/Min 6T Rolling Shutter Manufacturing Machine Hydraulic Cutting

8m/Min 6T Rolling Shutter Manufacturing Machine Hydraulic Cutting8m/Min 6T Rolling Shutter Manufacturing Machine Hydraulic Cutting
